GSI150 Intrinsically Safe Acoustic Emission Sensor 150kHz

Name: GSI150 Intrinsically Safe Acoustic Emission Sensor 150kHz
Brand: QingCheng Ltd.
Price: 200 USD

China GSI150 Intrinsically Safe Acoustic Emission Sensor 150kHz wholesale

Brand Name : QingCheng Ltd.

Model Number : GSI150

Certification : CE

Place of Origin : China

MOQ : 1 Piece

Price : USD200

Payment Terms : T/T

Supply Ability : 50 pieces per month

Delivery Time : 1-7 days

Packaging Details : Carton box (19cm *19cm *15cm)

Integral preamplifier : 26dB5V

Frequency range : 60KHz~400KHz

Resonant frequency : 150KHz

Sensitive Peak : >73dB

Using temperature : -20-170℃

Size(DxH) : 19mm*14mm

Housing material : SUS-304

Receiving surface material : Ceramic

Protection Grade : IP68

Weight : 26g

Contact Now

Product Description

Technical Specs
Resonant Freq. Ref V/(m/s)	150kHz
Frequency Range	60kHz-400kHz
Sensitivity Peak Ref V/(m/s)	>73dB
Integral preamplifier	26dB5V
Preamp. Impedance	50Ω
Working Temp.	Sensor:-20 to 170℃ Preamp:-20 to 60℃
Size(DxH)	Sensor:21.7x25 mm Preamp:19×14 mm
Weight	26 g
Case Material	SUS-304
Face Material	Ceramic
Protecting Grade	IP68
Connector	SMA
Connector Location	Top on preamplifier
Accessories
Signal cable model	RG178/RG316

GSI150 Intrinsically Safe Acoustic Emission Sensor 150kHz

Applications

The GSI150 is well suited for detecting equipment in harsh environment that requires intrinsic safety. It is useful for detecting the crack and fault of metallic equipment and monitoring structures such as pipelines, vessels, bridges etc.

Intrinsically Safe Acoustic Emission Sensor

IP68 Acoustic Emission Sensor
